Design

SOLIDWORKS Standard

• Design 3D parts, then assemble them into assemblies and generate 2D production drawings.
• Use specialized tools for designing welded structures, injection molds, and sheet metal, including features for weld seams, cooling channels, and bends.
• Check your design for potential issues, such as collisions, minimum wall thicknesses, and manufacturability with available techniques.
• Integrate electrical schematics (ECAD) with mechanical designs (MCAD) to, for example, test whether electronics fit within the enclosure.

SOLIDWORKS Professional

• All the above design features, plus…
• Use a library of commonly used parts, such as bolts, nuts, bearings, and profiles, saving time by not having to draw them yourself.
• Make informed design decisions by estimating the production costs of your design based on material usage, machining time, and other factors.
• Ensure compliance with CAD standards and drawing rules by having SOLIDWORKS automatically check your drawings for errors and inconsistencies, such as incorrect layer names, missing dimensions, or deviations from standard templates.

SOLIDWORKS Premium

• All the above design features, plus…
• Design and manage electrical wiring harnesses within your 3D design. Add cables and connectors, determine cable lengths and diameters, and verify whether the wiring harness meets requirements—useful for industries such as automotive, aerospace, and machinery.
• Design piping, tubing, and ducting for liquids, gases, and air. Define routes, add components, and determine the diameter and material of the pipes—features applicable to industries such as process engineering, shipbuilding, and HVAC installations.

Present

Visualize 3D models in a powerful and interactive way with Augmented Reality and Virtual Reality. Project a 3D model of a machine onto the table in your office and walk around it so you can see it from all sides. Or even step into the 3D model with VR glasses and walk through or around it as if you were there yourself.

And do you really want to take your presentations to and higher level? With SOLIDWORKS Professional and Premium you can use photorealistic rendering to generate images that are almost indistinguishable from the real thing. Useful for presenting designs in brochures, presentations and websites, for example. Here you can apply realistic materials and textures (such as wood, metal or plastic) to your 3D model and light it appropriately (studio light, ambient light or HDRI.

Develop

Generate files that can be used directly by 3D printer and control CNC machines with the convenient NC programming functions in the software.

Simulation

In SOLIDWORKS Premium, you get access to several simulation functions. For example, you can perform finite element analysis (FEA) to test the stress, deformation and displacement of parts and assemblies under certain forces.

Are you designing moving parts? Then you can also analyze the motion of assemblies for forces, velocities, accelerations and other parameters.
